M1 Series — a floodlight that keeps watch
Solar lighting and a 4G security camera in one IP66 body. Five models from 200W to 1500W — verified specifications, complete export documents, FOB terms.
- 【Battery】Brand-new A-grade LiFePO4, 30 Ah
- 【Cycle life】2,000 charge cycles
- 【Solar panel】A-grade mono 5V / 35W (450×350 mm)
- 【LEDs】68 pcs SMD5054, 1520 lm
- 【Camera】4MP (1440P), night vision, human detection
- 【Connection】4G (standard SIM) or WiFi version
- 【Body】275×235×56 mm, IP66, die-cast
- 【Control】Light control + remote control (radar sensor optional)
- 【Warranty】2 years
- 【Battery】Brand-new A-grade LiFePO4, 36 Ah
- 【Cycle life】2,000 charge cycles
- 【Solar panel】A-grade mono 5V / 45W (500×400 mm)
- 【LEDs】101 pcs SMD5054, 2420 lm
- 【Camera】4MP (1440P), night vision, human detection
- 【Connection】4G (standard SIM) or WiFi version
- 【Body】IP66, die-cast
- 【Control】Light control + remote control (radar sensor optional)
- 【Warranty】2 years
- 【Battery】Brand-new A-grade LiFePO4, 45 Ah
- 【Cycle life】2,000 charge cycles
- 【Solar panel】A-grade mono 5V / 50W (550×400 mm)
- 【LEDs】132 pcs SMD5054, 3042 lm
- 【Camera】4MP (1440P), night vision, human detection
- 【Connection】4G (standard SIM) or WiFi version
- 【Body】365×310×64 mm, IP66, die-cast
- 【Control】Light control + remote control (radar sensor optional)
- 【Warranty】2 years
- 【Battery】Brand-new A-grade LiFePO4, 54 Ah
- 【Cycle life】2,000 charge cycles
- 【Solar panel】A-grade mono 5V / 55W (600×400 mm)
- 【LEDs】175 pcs SMD5054, 3640 lm
- 【Camera】4MP (1440P), night vision, human detection
- 【Connection】4G (standard SIM) or WiFi version
- 【Body】410×350×68 mm, IP66, die-cast
- 【Control】Light control + remote control (radar sensor optional)
- 【Warranty】2 years
- 【Battery】Brand-new A-grade LiFePO4, 60 Ah
- 【Cycle life】2,000 charge cycles
- 【Solar panel】A-grade mono 5V / 60W (670×445 mm)
- 【LEDs】175 pcs SMD5054, 4210 lm
- 【Camera】4MP (1440P), night vision, human detection
- 【Connection】4G (standard SIM) or WiFi version
- 【Body】410×350×68 mm, IP66, die-cast
- 【Control】Light control + remote control (radar sensor optional)
- 【Warranty】2 years
Every unit ships with remote control, U-bracket, 3 m waterproof cable and screws — ready to install.
One light, two jobs
Lighting + security
A 4MP camera built into the floodlight body. No separate CCTV purchase, no extra wiring.
4G without subscription
Standard SIM slot — your customer's local data SIM, no cloud fees, no monthly cost.
Radar sensor (optional)
With the radar version: full brightness on motion, dim when idle. Saves battery through the whole night.
A-grade LiFePO4
Brand-new cells rated for 2,000 cycles. 18+ hours of discharge on a full charge.
IP66 die-cast body
Rain, dust and heat proof — built for outdoor installs all year round.
Full kit in the box
Lamp, panel, remote, U-bracket, 3 m cable and screws. Open the carton and install.
Real monitoring, from anywhere
Your customers check the yard from their phone — live view, night vision and motion alerts, with no subscription and no cloud account. That is the feature your customers will notice first.
- 4MP (1440P) HD video, day and night
- Human detection with push alerts to the phone
- Live view and playback in the app
- Works on a 4G data SIM or WiFi
- No cloud subscription — video stays local
Want to see it working? Ask us for a live demo video on WhatsApp.
Five sizes, one platform
| Model | Battery (LiFePO4) | Panel | LEDs | Brightness | Per carton | Carton size (cm) | GW (kg) |
|---|---|---|---|---|---|---|---|
| 200W PRO | 30Ah | 35W, 450×350 | 68 | 1520 lm | 7 | 65×47.5×38.5 | 21.8 |
| 400W PRO | 36Ah | 45W, 500×400 | 101 | 2420 lm | 6 | 62×52.5×43.5 | 26.9 |
| 600W PRO | 45Ah | 50W, 550×400 | 132 | 3042 lm | 5 | 58×52×43.5 | 26.1 |
| 1000W PRO | 54Ah | 55W, 600×400 | 175 | 3640 lm | 3 | 63×33.5×43.5 | 17.6 |
| 1500W PRO | 60Ah | 60W, 670×445 | 175 | 4210 lm | 2 | 70×23×48 | 14.2 |
| Colour temperature | 6500–7000K, cool white |
|---|---|
| Charging time | 8 hours of sunlight |
| Discharge time | 18 hours+ |
| Camera | 4MP (1440P), night vision, human detection |
| Connection | 4G (standard SIM) or WiFi version |
| Certifications | CE, RoHS |
| Warranty | 2 years, spare parts shipped with bulk orders |
In the box
Floodlight, solar panel, remote control, U-bracket, 3 m waterproof cable (XT60 plug) and expansion screws.
Homes, farms and businesses
Every batch passes aging and charge tests
Aging test racks
Units run on aging racks before packing — early failures never leave the factory.
Burn-in verification
Continuous burn-in confirms drivers, batteries and LEDs hold spec over time.
Charge / discharge test
Every battery batch is cycle-tested so the rated 18+ hours of light is real.
Common questions
What is the lead time?
10–15 days of production for bulk orders. Samples ship in 7–10 working days.
What are the payment terms?
T/T: 30% deposit, 70% against B/L copy. Other terms can be discussed for repeat orders.
Can I order a sample first?
Yes. A sample fee applies and is refunded with your first bulk order.
What if something fails in warranty?
2-year warranty. Free spare parts ship with bulk orders, and failed components are replaced within warranty.
Ready for prices?
Send the models and quantities you are considering. We reply with a written FOB quotation — including lead time and payment terms — within 24 hours.
